Industrial Reels 400, 450 & 550mm Range


Crown Plastics industrial reels have been designed to provide our customers a cost effective yet strong, durable product which is easy to assemble. All flanges and barrels are made from black UV recycled polypropylene.

The 400mm range is available in four different barrel lengths with a 150mm external barrel diameter. The benefit of the 400mm range is you can stack 9 reels of product per layer on a pallet.

The 450-550mm range is available in three different barrel lengths with a 250mm external barrel diameter.

All industrial reels in the 400, 450 and 550mm ranges are available assembled or unassembled. For the unassembled - all assembly instructions are supplied with orders and there is assembly video guides available.

We can supply customer names, logos and colours on all our industrial reels depending on volumes.

Flange Diameter: 400mm
Internal Barrel Diameter: 60mm
Barrel Length: 160mm
Barrel Diameter: 150mm
Pallet QTY (Local): 96
Pallet QTY (Interstate): 108

Flange Diameter: 400mm
Internal Barrel Diameter: 60mm
Barrel Length: 200mm
Barrel Diameter: 150mm
Pallet QTY (Local): 96
Pallet QTY (Interstate): 108

Flange Diameter: 400mm
Internal Barrel Diameter: 60mm
Barrel Length: 300mm
Barrel Diameter: 150mm
Pallet QTY (Local): 60
Pallet QTY (Interstate): 60

Flange Diameter: 400mm
Internal Barrel Diameter: 60mm
Barrel Length: 335mm
Barrel Diameter: 150mm
Pallet QTY (Local): 60
Pallet QTY (Interstate): 60

Flange Diameter: 400mm
Internal Barrel Diameter: 60mm
Barrel Length: 400mm
Barrel Diameter: 150mm
Pallet QTY (Local): 48
Pallet QTY (Interstate): 48

Flange Diameter: 450mm
Internal Barrel Diameter: 60mm
Barrel Length: 300mm
Barrel Diameter: 250mm
Pallet QTY (Local): 45
Pallet QTY (Interstate): 54

Flange Diameter: 450mm
Internal Barrel Diameter: 60mm
Barrel Length: 400mm
Barrel Diameter: 250mm
Pallet QTY (Local): 36
Pallet QTY (Interstate): 45

Flange Diameter: 450mm
Internal Barrel Diameter: 60mm
Barrel Length: 450mm
Barrel Diameter: 250mm
Pallet QTY (Local): 36
Pallet QTY (Interstate): 36

Flange Diameter: 550mm
Internal Barrel Diameter: 60mm
Barrel Length: 300mm
Barrel Diameter: 250mm
Pallet QTY (Local): 25
Pallet QTY (Interstate): 30

Flange Diameter: 550mm
Internal Barrel Diameter: 60mm
Barrel Length: 400mm
Barrel Diameter: 250mm
Pallet QTY (Local): 20
Pallet QTY (Interstate): 25

Flange Diameter: 550mm
Internal Barrel Diameter: 60mm
Barrel Length: 450mm
Barrel Diameter: 250mm
Pallet QTY (Local): 20
Pallet QTY (Interstate): 20
